A286 Wire | AMS 5737 | UNS S66286 | DIN 1.4980

AMS 5858 A-286 Wire, ASTM A638 AISI 660 Wire, Werkstoff 1.4980 A-286 Wire, A-286 Cold Drawn Wire, AISI 660 Spring Wire, A-286 High Strength Alloy Wire in India.

PM Industries manufactures, supplies, and stocks UNS S66286 A286 Wire in a range of diameters and conditions. A286 is an iron-nickel-chromium superalloy with additions of molybdenum, titanium, and vanadium, developed for service at elevated temperatures where standard austenitic stainless steels lose too much strength to be useful. The alloy is age-hardenable through titanium and aluminum precipitation, which allows it to reach tensile strengths significantly above the solution-annealed baseline after heat treatment. That combination of heat resistance and age-hardening capability is what keeps A286 consistently specified for high-temperature fasteners, springs, and structural wire applications.

UNS S66286 A-286 AISI 660 Wire Manufacturer, AMS 5858 A-286 Wire Supplier, ASTM A638 AISI 660 Wire Stockist, Werkstoff 1.4980 A-286 Wire Exporter in India.

A286 is classified as a superalloy, though it's iron-based rather than nickel-based. It sits between standard austenitic stainless steels in composition and cost, and nickel superalloys like 718 in performance. For applications that need more than 316L can provide at elevated temperatures but where the cost of gamma-prime strengthened nickel alloys isn't justified, A286 occupies a practical middle ground that has kept it in active aerospace and industrial specification for over 60 years.

Wire in the solution-annealed condition is the starting form for most fastener and spring production. A286 wire in the annealed condition is sufficiently ductile to be cold drawn, formed into spring coils, cold headed into bolt blanks, or otherwise worked into component geometry. After forming is complete, the components are aged at approximately 720°C for a specified time to develop the full precipitation-hardened mechanical properties. That sequence, form first then age, avoids the difficulties of forming the fully-hardened material.

Fastener applications are the most consistent industrial use for A286 wire. High-temperature bolts, studs, and nuts in jet engines, gas turbines, and industrial hot sections require fasteners that maintain clamping load at elevated temperature without creeping under the sustained tensile stress of bolt preload. Standard stainless steel fasteners relax at temperatures where A286 holds its preload reliably. That creep resistance under sustained load at temperature is what makes A286 the standard specification for high-temperature fasteners in aerospace and gas turbine applications.

Spring applications benefit from the same combination of fatigue resistance and strength at temperature. Springs in fuel system components, exhaust system mechanisms, and engine control linkages that operate at elevated temperatures need an alloy that maintains spring rate and fatigue life through the operating temperature range. A286 provides both, at a cost point well below nickel superalloy alternatives for spring applications that don't need the full temperature capability of alloys like 718.

Wire is available in solution-annealed condition in a range of diameters with full material certification to AMS 5525 and applicable specifications. Contact PM Industries for diameter, condition, coil or straight lengths, and pricing.

Specification A286 Iron-Base Superalloy Wire | UNS S66286 | AMS 5737

Specifications	ASME SA 240/ASTM A 240
Standard Sizes	1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
Width	10-2500mm
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand, blast, Brush, etching, etc
Thickness	0.1mm to 100 mm Thk
Hardness	Quarter Hard, Half Hard,Spring Hard, Soft, Hard
Stock available in form of	Shim Sheet, Rolls, Strip, Flats, Clad Plate, Plain Sheet, Plate, Sheet, Coils, Foils, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Blank (Circle), soft annealed, sheared, annealed, tread plate,descaled, Checker Plate
Profiling	Plasma Plate Cutting
Value added services	Plasma cutting, Waterjet cutting, Laser cutting, welding, edge preparation, etc.
Test Certificates	EN 10204/3.1B, NACE MR0103, NACE MR0175
	Raw Materials Certificate
	100% Radiography Test Report
	Third Party Inspection Report, etc

Available Types of A-286 AISI Wire

A-286 AISI Wire Sheets & Plates – Equivalent Grades

Grade	AMS	ASTM	UNS	Werkstoff (DIN)	Common Name
A-286 / AISI 660	AMS 5858	ASTM A638	S66286	1.4980	AISI 660 / A-286 Alloy

A-286 AISI Wire Sheet & Plate – Chemical Composition

Grade	C	Cr	Ni	Mo	Ti	Al	Mn	Si	V	Fe
A-286	0.08 max	13.5 – 16.0	24.0 – 27.0	1.0 – 1.5	1.9 – 2.35	0.35 max	2.0 max	1.0 max	0.10 – 0.50	Bal

A-286 AISI Wire Sheets & Plates – Mechanical Properties

Grade	Condition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness (HRC)
A-286 Wire	Cold Drawn & Aged	≥ 1240	≥ 1035	≥ 8	≈ 35 – 40
